OnePlus Ace 5 Ultra
Market Status: Upcoming
Key Specifications
Screen Size
6.83 inches (17.35 cms)
RAM + Storage
12 GB + 256 GB
Processor
MediaTek Dimensity 9400 Plus Octa core
Screen Resolution
1272 x 2800 pixels
Operating System
Android v15
Rear Camera
50+8 MP
Battery
6700 mAh | 100W Fast Charging
Status
Upcoming
Expected Price
Yet to be confirmed
Expected Launch Date
Yet to be confirmed
OnePlus Ace 5 Ultra Specifications
Key Specs
RAM
12 GB
Processor
MediaTek Dimensity 9400 Plus Octa core
Rear Camera
50+8 MP
Front Camera
16 MP
Battery
6700 mAh | 100W Fast Charging
Display
6.83″ (17.35 cm) 144Hz AMOLED
General
Operating System
Android v15
Custom UI
ColorOS
Performance
Chipset
MediaTek Dimensity 9400 Plus
CPU
3.73GHz, Single core, Cortex X925 3.3GHz, Tri core, Cortex X4 2.4GHz, Quad core, Cortex A720
No of Cores
8 (Octa Core)
Architecture
64-bit
Fabrication
3 nm
RAM
12 GB
RAM Type
LPDDR5X
Display
Screen Size
6.83 inches (17.35 cms)
Screen Resolution
1272 x 2800 pixels
Bezel-less display
Yes, with Punch-hole
Pixel Density
450 ppi
Display Type
AMOLED, Always-On display, Blue light filter, Dolby Vision, Glove Touch, HDR Vivid, Rain Water Smart Touch
Refresh Rate
144 Hz
Screen Protection
Yes
Color Reproduction
1B Colors
Design & Body
Height
163.41 mm
Width
77.04 mm
Thickness
0.32 inches (8.10 mm)
Weight
206 grams
Colours
Titanium, Phantom Black, Breeze Blue
Waterproof
Yes, Splash proof, IP65
Ruggedness
Dust proof, Water proof
Screen Unlock
Fingerprint, Face unlock
Main Camera
Camera Setup
Dual
Resolution
50 MP resolutionWide Angle lensf/1.8 aperture24 mm focal length 1.56" sensor size1µm pixel size
Camera Secondary
8 MP resolutionUltra-Wide Angle lensf/2.2 aperture16 mm focal length4.0" sensor size1.12µm pixel size
Sensor
CMOS image sensor, Exmor-RS CMOS Sensor
Optical Image Stabilisation
Yes
Flash
LED Rear flashScreen Front flash
Shooting Modes
Continuous Shooting High Dynamic Range mode (HDR)
Camera Features
Auto Flash Auto Focus Face detection Smile detection Touch to focus
Video Recording
3840x2160 @ 60 fps1920x1080 @ 240 fps1280x720 @ 480 fps
Video Recording Features
Dual Video Recording Slo-motion
EIS
Yes
Digital Zoom
20x
Front Camera
Camera Setup
Single
Resolution
16 MP resolutionWide Angle lensf/2.4 aperture23 mm focal length3" sensor size1µm pixel size
Video Recording
1920x1080 @ 30 fps1280x720 @ 30 fps
Battery
Capacity
6700 mAh
Quick Charging
Yes, 100W Super Flash Charging, 100% in 39 minutes
USB Type-C
Yes
Storage
Internal Memory
256 GB
External Storage
No
Network & Connectivity
SIM Slot(s)
Dual SIM SIM1: Nano SIM2: Nano
Network Support
2G, 3G, 4G, 5G
VoLTE
Yes
SIM 1
5G:FDD N1 / N3 / N5 / N8 / N26 / N28 ; TDD N38 / N40 / N41 / N48 / N66 / N77 / N78 / N79 4G:TD-LTE 2600(band 38) / 2300(band 40) / 2500(band 41) / 2100(band 34) / 1900(band 39) / 3500(band 42) / 3500(band 48) ; FD-LTE 2100(band 1) / 1800(band 3) / 900(band 8) / 700(band 28) / 1700(band 4) / 850(band 5) / 1700(band 66) / 850(band 18) / 850(band 19) / 850(band 26)
SIM 2
5G:FDD N1 / N3 / N5 / N8 / N26 / N28 ; TDD N38 / N40 / N41 / N48 / N66 / N77 / N78 4G:TD-LTE 2600(band 38) / 2300(band 40) / 2500(band 41) / 2100(band 34) / 1900(band 39) / 3500(band 42) / 3500(band 48) ; FD-LTE 2100(band 1) / 1800(band 3) / 900(band 8) / 700(band 28) / 1700(band 4) / 1700(band 66) / 850(band 5) / 850(band 18) / 850(band 19) / 850(band 26)
Wi-Fi
Yes, with a/ac/ax/ax 6GHz/b/be/g/n/n 5GHz, MIMO
Wi-Fi Features
Mobile Hotspot
Bluetooth
Bluetooth v5.4
GPS
Yes with A-GPS, Glonass
USB Connectivity
USB 2.0, USB Type-C, Mass storage device, USB charging
Multimedia
Loudspeaker
Yes
Audio Jack
Yes, USB Type-C
Video Player
Yes, Video Formats: MP4
Sensor
Fingerprint Sensor
Yes
Other Sensors
Light sensor, Proximity sensor, Accelerometer, Compass, Gyroscope
Disclaimer: While we strive for accuracy, specifications listed here may differ from the actual product and are not guaranteed to be 100% correct. Please verify all details with the retailer before purchase.
